NeuroMaestro

A modular neuroimaging preprocessing pipeline for HPC clusters, with both a GUI and CLI. Pipeline parameters and analysis workflows are configured through YAML files, allowing flexible customization without modifying the underlying code.

Full handbook: https://georgiacenterfordevelopmentalscience.github.io/NeuroMaestro/

---

Supported Pipelines

The pipeline is organized into four stages. The software used at each stage is configured per-project and can be customized; the examples below reflect our defaults.

Stage	Description	Example software
Data preparation	Unzip raw data, convert DICOM to BIDS	dcm2bids
Intermediate steps	Any intermediate step required before modality pipelines (staged pipelines only)	AFNI @SSwarper
BIDS pipelines	Modality preprocessing that runs directly on BIDS data	fMRIPrep, XCP-D, QSIPrep, QSIRecon
Quality control	Image quality metrics	MRIQC

The key distinction between pipeline types:

• Staged pipelines (--staged-prep) require an intermediate structural or bias field correction step before modality preprocessing. Designed for workflows like AFNI that operate on locally processed data, but can be adapted to any pipeline requiring intermediate steps.
• BIDS pipelines (--bids-prep) run directly on BIDS-formatted data without intermediate steps (e.g. fMRIPrep, QSIPrep).

---

Installation

Prerequisites: Python 3.10+, HPC cluster with SLURM or PBS, neuroimaging software installed on the cluster.

git clone https://github.com/GeorgiaCenterforDevelopmentalScience/NeuroMaestro.git
cd NeuroMaestro
pip install -e .

# Or developmental mode
# pip install -e .[dev]

# Verify
neuromaestro --help
neuromaestro-gui --help

---

Configuration

Each project requires a {project}_config.yaml in the project_config/ folder of your config directory, the one --config-dir points at. Run neuromaestro generate-config {project} to create one from the template, then fill in paths, HPC modules, and pipeline options. Output folder names are defined in this file and can be changed freely.

Modalities available under --bids-prep and --staged-prep are declared in config.yaml.

Expected output files for --resume are defined in config/results_check/{project}_checks.yaml. Edit this file to specify which files should exist (and optionally their minimum size) for a subject to be considered complete.

HPC scheduler, resource profiles (memory, walltime, CPU), and submission flags are configured in hpc_config.yaml. Recommended values are pre-filled; update partition names and resource limits to match your cluster.

---

Quick Start

First-time setup: scaffold config and script templates into your study directory.

neuromaestro init /path/to/my_study
# Optionally export to ~/.bashrc so you can omit --config-dir on every command.
# If you skip this, pass --config-dir /path/to/my_study/config explicitly instead.
export NEUROMAESTRO_CONFIG_DIR=/path/to/my_study/config

This copies config.yaml, hpc_config.yaml, project_config/, results_check/, and script templates. Edit them to match your cluster and project before running.

---

# Launch the GUI
neuromaestro-gui   # open http://localhost:8050 in your browser

Or use the CLI. Start with a dry-run on one subject to verify the plan:

neuromaestro run \
  --subjects 001 \
  --input /data/BIDS \
  --output /data/processed \
  --work /data/work \
  --config-dir /data/config \
  --project my_study \
  --session 01 \
  --bids-prep rest \
  --dry-run

Full pipeline — all stages, multiple subjects:

neuromaestro run \
  --subjects subjects.txt \
  --input /data/raw \
  --output /data/processed \
  --work /data/work \
  --config-dir /data/config \
  --project my_study \
  --session 01 \
  --prep unzip_recon \
  --intermed volume \
  --staged-prep cards,kidvid \
  --staged-post cards,kidvid \
  --bids-prep rest,dwi \
  --bids-post rest,dwi \
  --mriqc all

Dependencies are enforced automatically by the scheduler.

---

CLI Reference

Core options

Option	Description
--subjects	Comma-separated subject IDs or path to a .txt file
--input	Input BIDS directory
--output	Output directory
--work	Work directory (logs, database, intermediate files)
--config-dir	Path to config directory (contains config.yaml, hpc_config.yaml, project_config/). Optional if $NEUROMAESTRO_CONFIG_DIR is exported.
--project	Project name (must match a {project}_config.yaml)
--session	Session label (e.g. 01)

Pipeline options

Option	Description
--prep	Data preparation: unzip, recon, unzip_recon
--intermed <tasks>	Intermed tasks to run (comma-separated, e.g. volume). Staged prep tasks depend on these when given. Omit it only when the intermed outputs already exist from an earlier run.
--bids-prep <modalities>	BIDS pipeline preprocessing (comma-separated, e.g. rest,dwi)
--bids-post <modalities>	BIDS pipeline postprocessing (comma-separated, e.g. rest,dwi)
--staged-prep <modalities>	Staged pipeline preprocessing (comma-separated, e.g. cards,kidvid)
--staged-post <modalities>	Staged pipeline postprocessing (comma-separated, e.g. cards,kidvid)
--mriqc	Quality control: individual, group, all

Run options

Option	Description
--dry-run	Preview the execution plan without submitting jobs
--resume	Skip subjects whose expected outputs already exist
--skip-bids-validation	Skip pre-run BIDS validation
--skip-preflight	Skip pre-flight config and filesystem checks
--wait	Wait for submitted jobs to finish before exiting
--polling-interval	Seconds between job status checks when --wait is set. Default 60.

---

Resume a Partial Run

neuromaestro run \
  --subjects subjects.txt \
  --input /data/BIDS \
  --output /data/processed \
  --work /data/work \
  --config-dir /data/config \
  --project my_study \
  --session 01 \
  --bids-prep rest \
  --resume

--resume checks each subject's expected output files (defined in config/results_check/{project}_checks.yaml) before submitting. Subjects that already have valid outputs are skipped silently.

---

Directory Structure

Input (BIDS)

input_directory/
├── sub-001/
│   └── ses-01/
│       ├── anat/
│       ├── func/
│       └── ...
└── sub-002/
    └── ...

Output Example

output_directory/
└── project_name/
    ├── raw/
    ├── BIDS/
    ├── AFNI_derivatives/
    ├── BIDS_derivatives/
    │   ├── fmriprep/
    │   ├── xcpd/
    │   ├── qsirecon/
    │   └── qsiprep/
    └── quality_control/
        └── mriqc/

work_directory/
└── project_name/
    ├── log/
    └── database/

---

For questions or issues, contact QiuyuYu or open a repository issue.
