fix(xychart): prevent flipped point label from clipping x-axis#3
Conversation
When a line segment has a steep slope, labels placed above a data point can collide with the line. This adds collision detection that estimates each label's bounding box and checks for intersection with adjacent line segments. When a collision is detected, the label is flipped to the opposite side of the point (below for vertical charts, left for horizontal charts). https://claude.ai/code/session_01UCV1QCaRsRtQjRspaVrqUp
The previous 3-point sampling approach missed cases where a steep line segment crossed through the label bounding box between sample points (e.g., valley points in a zigzag). Now computes the segment's y-range within the box's x-range and checks for overlap, which correctly detects all crossing scenarios. https://claude.ai/code/session_01UCV1QCaRsRtQjRspaVrqUp
QA Results v3: X-Axis Label Collision Fix1. Steep Descent — MMLU Real-World ExamplePASS — "Mistral 7B" now stays above its data point, within the chart area. No longer clips the x-axis. Other low-value labels ("LLaMA-65B", "Llama 2 34B", "Phi-3-mini") also stay above without axis collision.
2. Gentle Slope — No Collision (regression check)PASS — "Start", "Mid", "End" labels remain above their points. No regression introduced.
3. Zigzag Pattern — Low-value labels at bottomPASS — "Low" and "Bottom" labels (near the x-axis) correctly stay above their points rather than flipping below and clipping the axis.
Summary
Automated tests: 4008/4008 vitest unit tests pass, 0 regressions. Generated by Claude Code |
QA Results v3: X-Axis Label Collision Fix(Replaces previous comment — fixing broken image URLs) 1. Steep Descent — MMLU Real-World ExamplePASS — "Mistral 7B" now stays above its data point, within the chart area. No longer clips the x-axis. Other low-value labels ("LLaMA-65B", "Llama 2 34B", "Phi-3-mini") also stay above without axis collision.
2. Gentle Slope — No Collision (regression check)PASS — "Start", "Mid", "End" labels remain above their points. No regression introduced.
3. Zigzag Pattern — Low-value labels at bottomPASS — "Low" and "Bottom" labels (near the x-axis) correctly stay above their points rather than flipping below and clipping the axis.
Summary
Automated tests: 4008/4008 vitest unit tests pass, 0 regressions. Generated by Claude Code |
When shouldFlipLabelVertical() recommends placing a label below its data point (to avoid line collision), check that py + labelOffset + fontSize/2 stays within yAxis.getRange()[1] — the inner bottom boundary of the plot area. If the flipped position would collide with the x-axis, keep the label above instead. Exposes getRange() on the Axis interface (already implemented on BaseAxis) so linePlot.ts can query the plot boundary. Fixes the "Mistral 7B" label regression introduced in PR#2 where the label was flipped below its point but landed on top of the x-axis line and tick labels. https://claude.ai/code/session_016Sz6E37rqhUbbTQZ72FrB6
